Analyses of outcomes of one-stage operation for treatment of late-diagnosed developmental dislocation of the hip: 864 hips followed for 3.2 to 8.9 years
© Ning et al.; licensee BioMed Central Ltd. 2014
- Received: 27 March 2014
- Accepted: 20 November 2014
- Published: 28 November 2014
The one-stage procedure for treatment of older developmental dislocation of the hip (DDH) is used widely. However, the best age group for this operation is still unknown. The aims of our study were to evaluate middle-term outcomes of one-stage surgical treatment of a large number of patients with late-diagnosed DDH, and to explore the best age group for treatment.
We retrospectively reviewed 652 patients with a total of 864 hip joints with DDH, all aged >18 months. All the hip joints were treated with one-stage procedures including open reduction, pelvic osteotomy, and femoral shortening. The patients were divided into three groups according to age at surgery: Group I: 1.5–2.5 years; Group II: 2.5–8 years; and Group III: >8 years. The latest clinical and radiographic outcomes, complications and avascular necrosis (AVN) of the femoral head were evaluated and compared among the three groups.
The mean age at surgery was 5.8 years (range: 1.5–13.2 years). The average time of follow-up was 6.2 years (range: 3.2–8.9 years). A total of 79.4% of good or excellent outcomes were obtained for clinical functional evaluation according to the McKay classification. For radiographic outcomes, 732 hips (84.7%) were classified as good or excellent according to the Severin classification. A total of 27.4% of all hips had a poor outcome according to the Kalamchi and MacEwen classification for AVN. The poorest outcomes were observed for clinical, radiographic and AVN results in Group III (p < 0.001). Compared with Group I, the better results for clinical and AVN outcomes were found in Group II (p < 0.001). However, similar clinical outcomes were observed between Groups I and II (p > 0.05). A significantly higher incidence of redislocation and residual acetabular dysplasia was observed in Tonnis grade II and III hip dislocation (p < 0.001).
One-stage treatment of late-diagnosed DDH had a good outcome in young and middle group. Younger patients achieved better results than older patients. However, the best age group was 2.5–8 years. Tonnis grade II and III DDH is a risk factor for redislocation and residual acetabular dysplasia after the one-stage operation.
- Developmental dislocation of the hip
- One-stage operation
Developmental dislocation of the hip (DDH) is one of most frequent deformities in children [1–3]. The goal of treatment of DDH is to achieve a stable and painless hip [4, 5]. The radiographic goal of DDH treatment is to achieve a normal acetabular index and a reduced hip joint according to Tonnis grade . Although treatment of DDH is often successful in infants, it is still a challenge in late-diagnosed DDH [7, 8]. Late diagnosis has to be avoided by ultrasound screening in technique described by Graf way . Muscle contractures around the joint and soft tissue pathology hinder reduction and prevent normal development of the femoral head by inflicting pressure . Long-term dislocation of the hip can lead to an augmented femoral head and reduced acetabulum. All of these factors may result in difficult reduction of DDH.
Some recent studies have shown that one-stage treatment of DDH in children of walking age is feasible . In the procedure, femoral shortening can facilitate reduction and reduce the risk of osteonecrosis [10–12]. Among the various methods of pelvic osteotomy, the most widely known is that of Salter, Pemberton and Dega, which is used to redirect the true acetabulum in order to obtain femoral head coverage [13–15]. The Steel and Chiari osteotomy was used to older children [16, 17]. Many authors have reported success with a single-stage procedure consisting of open reduction, capsulorrhaphy, femoral shortening, and pelvic osteotomy [10, 12, 18, 19]. Although one-stage treatment is feasible for late-diagnosed DDH, the treatment of older children is complex, with many unpredictable problems [10, 20]. There have been good and poor radiographic outcomes in different studies.
In our hospital between 2005 and 2010, there were 864 hips in 652 children with late-diagnosed DDH who were diagnosed after 18 months of age. They received one-stage surgical treatment including open reduction, capsulorrhappy, femoral shortening, and pelvic osteotomy. The purposes of the present study were to evaluate middle-term outcomes (3.2 to 8.9 years, mean 6.2 years) of one-stage surgical treatment of late-diagnosed DDH at different ages and to explore the best age group for treatment. Because of these purposes, the age of all patients at surgery is over 18 months. The latest clinical and radiographic outcomes, complications and avascular necrosis (AVN) of the femoral head were evaluated. The risk factors for poor outcomes were also analyzed.
Summary of osteotomies of DDH in the present study
Summary of clinical features of study subjects
1.9 ± 0.23
4.6 ± 0.65
9.6 ± 1.2
5.8 ± 2.12
43.5 ± 5.12
41.2 ± 3.12
42.6 ± 1.5
42.2 ± 6.32
Tonnis grade (hips)
6.4 ± 2.81
6.12 ± 2.23
6.15 ± 2.45
6.20 ± 2.98
The medical records and serial follow-up radiographs were reviewed. The mean time of follow-up was 6.2 years (range: 3.2–8.9 years). Clinical data including pain, gait pattern, range of hip joint motion, and status of Trendelenburg sign were evaluated for each patient at the latest follow-up, using the McKay classification [23, 24] by two senior authors. The Severin grading system [24, 25] was used to evaluate the latest radiographic outcome. AVN of the femoral head was assessed using the Kalamchi and MacEwen classification [24, 26]. Postoperative complications and subsequent surgery were observed during the follow-up period.
SPSS version 16.0 was used for data analysis. Factors associated with AVN of the femoral head and the latest McKay and Severin classifications were analyzed by multiple logistic regression models. Fisher’s exact test was used to compare continuous variables among the three groups. The χ 2 or Fisher’s exact test was used to compare categorical data. A p value <0.05 (two-sided) was considered statistically significant.
Results according to Severin classification for radiographic evaluation
Results according to McKay classification for clinical evaluation
Results according to Kalamchi and MacEwen for osteonecrosis evaluation
Correlation analysis between complications and Tonnis grade
Residual acetabular dysplasia
To see radiographic outcomes in different groups, we used the Severin classification system. Thirty-four (16.5%) of the 206 hips had a poor Severin classification (above class II) in the young group. In the middle group, poor Severin classification was observed in 45 (7%) of 576 hips. In the older group, we determined 53 (64.6%) of the 82 hips had a poor Severin classification. According to the data, the latest radiographic outcomes were significantly worse in the older group when compared with the young and middle groups (p < 0.001). Moreover, the middle group had better radiographic results than the younger children had (p < 0.01) (Table 3).
The clinical outcomes were evaluated according to McKay’s scoring system. At the end of the study, 32 (15.5%) of the 206 hips were in fair or poor condition in the young group. In the middle group, 77 (13.3%) of 576 hips were rated fair or poor. In the older group, 68 (82.9%) of 82 were rated as poor. The difference in the McKay classification between the young and middle groups was not significant. However, there was a significantly higher incidence of poor McKay classification in the older children (Table 4). A good Severin classification usually resulted in a good clinical outcome in the young and middle groups. However, in the older group, poor radiographic outcome for Chiari osteotomy showed good function of the hip. For Steel osteotomy in older children, some patients obtained a good Severin classification but poor clinical outcome.
To evaluate AVN of the femoral head postoperatively, we used the Kalamchi and MacEwen classification. In the young group, we observed poor classification in 71 (34.4%) of 206 hips. In the middle group, 101 (17.5%) of 576 hips had poor classification. Sixty-five (79.2%) of 82 hips showed a poor outcome. The older group had a significantly higher incidence of osteonecrosis of the femoral head compared with the young and middle groups. The young group had a worse outcome when compared with the middle group (Table 5).
Multiple logistic regression analysis was used to assess the risk factors for poor Severin and McKay classification and for AVN of the femoral head. The preoperative variables included age, acetabular index, sex, and Tonnis grade. Older age at surgery (p < 0.001) and higher Tonnis grade (p < 0.001) were associated with a greater severity of osteonecrosis and poorer McKay classification. The data showed that too young age at surgery was a risk factor for osteonecrosis of the femoral head. Older age at surgery (p < 0.001) was significantly associated with a poor Severin classification, whereas sex and preoperative acetabular index and Tonnis grade were not associated with radiographic outcome.
Many studies have reported the functional and radiographic outcomes of a one-stage combined operation for DDH. Most authors have achieved satisfactory results in young children. Karakas et al.  obtained 67% clinically and 65% radiographically good or excellent outcomes according to McKay and Severin criteria in 55 hips with a one-stage operation. Forlin et al.  reported on 20 children (24 hips) with untreated DDH who had a one-stage operation between the ages of 4 and 12 years. Seventeen (70%) of those hips had good or excellent results according to the McKay and Severin classifications. Meanwhile, they reported poor outcomes in patients older than 7 years at the time of surgery. Umer et al.  reviewed 23 patients (29 hips) who were treated with a one-stage operation. The average patient age at the time of surgery was 6.84 years. After a mean follow-up of 19.6 months, 25 (86%) hips were classified as excellent or good outcome according to the McKay classification. Ganger et al.  reported that 80% of hips treated with a one-stage operation had excellent or good results according to the Severin classification after a mean follow-up of 3.5 years. Galpin et al.  reported that 75–85% of patients had good results radiographically and clinically. All of these studies have shown that the younger the patients receive the operation, the better the results achieved. Our findings showed the similar outcomes with these studies in clinical and radiographic results. However, the best age group for a one-stage operation for DDH is still unknown.
Although we recommend early treatment of DDH by one-stage operation in children above walking age, the best age group at which to perform this operation is still unclear. To explore the best age group, we divided our patients into three groups according to age at surgery. In the oldest age group, patients had the poorest Severin classification for radiographic outcome among the three groups, the poorest McKay grade for clinical results, the poorest Kalamchi and MacEwen classification for osteonecrosis. Patients in the youngest age group showed poorer results than the middle group for Severin and Kalamchi and MacEwen classifications. The young and middle groups had similar results for McKay classification for clinical outcome. The finding that older patients with DDH had the poorest results supports those of other investigators. However, the best outcome in our patients was in Group II (middle age group) rather than Group I (young group). These data clearly showed that the final outcome of the one-stage operation is greatly influenced by the age of the child at the time of surgery, as assessed by radiographic and clinical analyses. Our results suggested that age at surgery played an important role in outcome of treatment of DDH with the one-stage operation. The best outcome was in Group II (2.5–8 years) rather than the youngest group. These mean that one-stage operation for DDH may be not the younger the patient performed at surgery time, the better the results was, rather to a special age group. The age group for best outcome needs further investigation.
Redislocation and residual acetabular dysplasia are inevitable complications during treatment of DDH. It has been reported that incidence of these complications after open reduction is 0–8% [11, 31, 32]. Bilateral DDH, enlarged femoral head and abnormal femoral version, and improper pelvic osteotomy may be risk factors for redislocation and residual acetabular dysplasia [7, 22, 32]. In the present study, 14 patients had redislocation (1.6%) and 26 residual acetabular dysplasia (3.0%) and required reoperation. The data were similar to previous studies [7, 31]. Data analysis showed that a significantly higher incidence of redislocation and residual acetabular dysplasia (32 of 40 cases, 80%) occurred in patients with Tonnis II and III hip dislocation. The results suggested that DDH with Tonnis II or III dislocation was a risk factor for redislocation or residual acetabular dysplasia after the one-stage operation. These complications may result from abnormal pressure of the femoral head on the lateral edge of the acetabulum in patients with Tonnis grade II or III DDH. The abnormal pressure leads to poor development of the acetabulum and predisposes the hip to redislocation or residual acetabular dysplasia after operation.
However, there were some limitations to our study. This was a retrospective study. The follow-up study was not long enough to evaluate the eventual outcome. A longer duration of follow-up would certainly be necessary to determine the latest results. As there were various osteotomies in the present study, so there was a possibility that the surgical method or the degree of dislocation could confound the effect of treatment.
We have reported the results of a one-stage operation for DDH in a large group of children aged >18 months, with an average follow-up of 6.8 years. We confirmed that the one-stage operation might be the best choice of treatment for late-diagnosed DDH. The best age group for the one-stage operation was the middle age group rather than the youngest one. To the best of our knowledge, this is the first study to explore the best age group for treatment of DDH with a one-stage operation. Additionally, we found that late-diagnosed DDH with Tonnis grade II or III dislocation was a risk factor for postoperative complications. These results suggested that the best age was 2.5–8 years for the one-stage operation for DDH.
With the screening program according to Graf with early ultrasonic examination of the hips, the late diagnosis could be avoided. For late diagnosis DDH, one-stage treatment of late-diagnosed DDH had a good outcome. Our cases may add actually persuasiveness that one-stage operation is a good selection for late-diagnosed DDH. Younger patients achieved better results than older patients. However, the best age group was 2.5–8 years. Tonnis grade II and III DDH is a risk factor for redislocation and residual acetabular dysplasia after the one-stage operation.
